Key Features:

Built-in protection: Over current protection, over voltage protection, short circuit protection

More than 87% conversion efficiency

Compatible with HP Notebook

Replace Adapter P/N :

DELL PA-10, PA-12, NADP - 90KB, PA-1900-02D, PA-1900-02D2

Specifications

AC Socket

IEC60320 C8(Small 2 pins) ADP193-31

Input voltage: 100-240VAC

Input frequency: 50/60Hz

Output Voltage: 18.05-19.95V

Output Current: 0-3.42A

Ripple/Noise≤250mV

Efficiency: ≥87% at full load

Hold up time: ≥5ms

Temperature range: Operating 0C to 40C

Output Watt: 65W

Dimension:108*46*30mm(L*W*H)

Compatibility:

Dell Inspiron 300M, 500M, 505M, 510M, 600M, 630M, 640M, 700M, 710M, M101z, M5010R, M102z, M501R

Dell Inspiron 1420, 1501, 1521, 1525, 1526, 1720, 1721,14V,15R, 14R,13Z,15Z

Dell Inspiron 6000, 6400, 8500, 8600, 9200, 9300, 9400

Dell Inspiron E1405, E1505, E1705

Dell Latitude D400, D410, D420, D430

Dell Latitude D500, D505, D510, D520, D530, D531

Dell Latitude D600, D610, D620, D630

Dell Latitude D800, D810, D820, D830

Dell Precision M20, M60, M70

Dell Vostro 1014, 1015, 1088, 3300, 3400

Package Content

1 x Notebook adaptor
